Description
Ranco A30-2210 Temperature Control for Refrigerator and Beverage Coolers
The Ranco® A22, A30 and 9530 Series Constant Differential Temperature Controls are designed to switch electrical components of refrigeration systems in response to sensed temperatures.
Features and Benefits
- Laser-welded stainless steel bellows.
- Fixed or adjustable temperature settings.
- High-amperage contacts.
- Pneumatic action provided by vapor-filled capillary or capillary with bulb sensing elements.
- Constant On or Off positions available.
- Choice of mounting brackets, adjustment ranges and cams, and slotted or flatted shafts.
- Standard 1/4” quick-connect terminals with optional screw terminals.
Ranco #A30-2210 Specifications
- Item: Single Pressure Controls
- Switch Action: Opens on High/Low Pressure
- Connection: Copper Capillary withFlare Nut
- Range (PSI): 100 to 400
- Differential Pressure (PSI): 40 to 150
- Mounting: Universal
- Enclosure: NEMA 1
- Country of Origin (subject to change): Mexico
- Switch Type: SPDT
- Pressure Connection: 36 in Capillary with Flare Nut
- Type: High Pressure
- Capillary Length (In.): 36 in
- Reset: Auto
- Function: To Protect the Compressor from Excessive System Pressure which Could be Caused by Condenser Fan Failure
- Application: For Refrigerants R 12, R 22, R 134A and R 502
